VOSSLOH SCREW Ss8 for Sleeper Rail

SS8 screw spikes are used to secure the steel rail to the wooden or concrete sleeper, ensuring the rail stays in place and aligned. In railway engineering, an SS8 screw spike (also known as a rail screw spike) is a type of railroad spike designed to fasten a rail to a sleeper (or tie)

Kunshan Signum Machinery Technology Co., Ltd. specialise in manufacturing railway Screw Spikes to various international standards, including AREMA for North America, EN 13481 and UIC 864-2 for European railways, and GB for China, We are able to customize railway screw spikes according to our customer's specific requirements.This includes custom length, thread, material, grade and finish.

Ss series rail screw spike:
Ss series rail screw spike is designed according to the standard UIC864-1
Type    Dimension (mm)    Weight (Kg)
Ss5-150    M24×150    0.545
Ss8-140    M24×140    0.528
Ss8-150    M24×150    0.548
Ss8-160    M24×160    0.568
Ss23-160    M24×160    0.645
Ss25-165    M24×165    0.625
Ss35-161    M24×160    0.657

ASTMA66-87 screw spike:
We also supply the railway sleeper screw spikes for the USA with the standard ASTMA66-87, cold bending 90 degree without bracks. Standard strength 65000PSI or high strength 100000psi is available. Common sizes include 3/4", 7/8", 15/16"

Screw spike with big disk:
Screw spike with big disk for Africa and South America
Rail screw spikes with big disk are mostly applied in South America and Africa
Diameter: 22mm, 23mm
Length: 115mm, 133mm, 178mm

3V sleeper screw:
The mechanical properties of 3V sleeper screw are in accordance with NF F 50006,
Tension strength: 700MPA (min),
Elongation: 12% (min),
Cold bending: 30 degree without cracker.
Type    Dimension(mm)    Weight (Kg)
V20-135    M20×135    0.438
V23-115    M23×115    0.48
V23-135    M23×135    0.55
V23-155    M23×155    0.62
V23-215    M23×215    0.78
V26-115    M26×115    0.55

High tension screw spike:
High tension screw spike is also called as screw spike for wooden sleeper. Size: 15/16×6-1/2.
Tensile Strength    Yield Strength    Elongation    Reduction of Area    Hardness
120,000psi(min)    92,000psi(min)    14%(min)    35%(min)    HRC22-HRC3

Coach screw:
Coach screw is usually used for the mining industry in South Africa.
Diameter: 18mm
Length: 65mm and 75mm
Material: Q195 and Q235

DHS35 screw spike:
DHS35 rail sleeper screw spike can be used as a part of SKL14 rail fastening system
Diameter: 24mm
Length: 158mm and 161mm
T type screw spike :
T type screw spike with round thread, according to the standard NF-F 50014

Double-head screw spike:
Railway sleeper screw spike with two ends is also called as double-head screw spike, usually used together with the Nabla clip system. It is very popular in Africa. For meeting with the bending test, we use special material TD16 to produce the sleeper screw, bending 30 degree and straightening it, without cracker.
Size: 23×174
Material: TD16

Dive spike:
The dive spike has wide applications, including timber construction highway crossing planks and panels, bridge and trestle guard rails, motor car set-off, docks, etc. The dive spike has advantages of low cost of installation and maintenance. Meet with the standard ASTMA66-87, cold bending 90 degree without cracker.
Main Size: 5/8×10 and 7/8×7
Material: 35#
Tensile Strength    Yield Strength    Elongation 2"
414Mpa    207Mpa    >18%

Hex head screw spike:
Screw spike with slotting head, as per UIC864-1
Size: 24×131 and 24×150
Any other type can be customized according to customers' drawings and grade.
